• SEBO Complete Chassis for AUTOMATIC X2 and X5 — Gray Black
1 1

SEBO

SEBO Complete Chassis for AUTOMATIC X2 and X5 — Gray Black

SEBO Complete Chassis for AUTOMATIC X2 and X5 — Gray Black

$56.00 USD
$56.00 USD
Sale Sold out
Shipping calculated at checkout.

5321GS
Authorized Sebo Dealer Factory warranty, extended free where we can
Free Shipping On Eligible Orders $100+
Secure Checkout SSL Encrypted

Shipping Information

We offer free standard shipping on eligible orders of $100 or more within the 48 contiguous United States. Eligibility is calculated on the merchandise subtotal after discounts and before tax.

Most in-stock orders using standard shipping are processed within 1-5 business days, and most arrive 2-11 business days after they are placed. Backordered and special-order items may take longer. Expedited UPS Ground is available at checkout for an extra charge, including on orders that qualify for free standard shipping. See our Shipping Policy for details.

Returns & Exchanges

Need to return an item? We’re happy to help. Eligible items may be returned by requesting authorization within 35 days of delivery. Once approved, your return must reach us within 21 days.

Return eligibility

Items must be unused, in new condition, and include their original packaging and all accessories. Machines that use water cannot be returned once unboxed, unless defective upon arrival.

Shipping and refunds

For non-defective returns, customers cover return shipping. Original shipping charges are nonrefundable. If your order included free shipping, our actual outbound shipping cost will be deducted from your refund. Eligible returns have no restocking fee.

Received a defective item?

Contact us so we can help arrange a prepaid return label and replacement.

Please review our Return & Refund Policy for complete details and exclusions.

Warranty Information

All products sold by Vacuums and More come with the manufacturer's warranty. Warranty terms vary by brand and product.

With 35 years of industry experience, we stand behind every product we sell. Contact us for warranty support.

View full details

SEBO Complete Chassis for A...

$56.00

Product details

Once the frame under a SEBO AUTOMATIC X2 or AUTOMATIC X5 has split, part 5321GS replaces it outright rather than patching it: the whole chassis, moulded in gray black to match the rest of the machine.

The chassis is the structural centre of an upright. Motor, brush roll bearings, wheel axle and the swivel neck all locate off it, and the accuracy of those mountings relative to each other is what keeps the roll parallel to the floor and the nozzle sitting level across its width. Frame damage rarely announces itself as frame damage. A boss that has split around its screw shows up instead as bristles worn down at one end of the roll, a knock that appears over floorboards, or a machine that leans and leaves a narrow strip of carpet untouched on one side. Working through those symptoms one part at a time seldom ends anywhere useful, whereas a sound frame resets all of the alignments together.

Treat the job as a transfer rather than a repair. Wheels, axle, bottom plates and the pile adjustment hardware come off the old frame and go straight onto the new one, so it is the natural moment to look each of them over with the machine in pieces. Bearings that have been running in a distorted frame often turn out to be rough as well.

  • Fits: SEBO AUTOMATIC X2 and AUTOMATIC X5
  • Colour: gray black
  • Part number: 5321GS
  • Supplied: complete chassis
  • Carries: the motor, the roll bearings and the wheel axle
  • Failure to look for: split mounting bosses, hairline cracks near screw points
  • Related part numbers for the same two machines: 5053 chassis axle, 5051GS axle with wheels, foot pedal and spring, 5819GS complete wheel, 5413GS front bottom plate, 5414GS rear bottom plate, 5230GS bumper set

Genuine SEBO chassis, shipping in 2–5 business days.
