Carpet Pro Switch & Harness...
$33.99
Product details
Part C352-2800 bundles the on/off switch with its wiring harness as one piece, sized to fit a Carpet Pro SCBP1 backpack, and the identical assembly is used on the Powr-Flite PF300BP, PF600BP, and PF1000BP.
A switch that has cycled thousands of times tends to fail in a few predictable ways: the machine drops out at random while the operator is mid-task, it needs a wiggle before it will fire up, or it keeps spinning for a beat after being switched off. Since the harness comes attached to the switch, replacing the pair swaps out the wiring connections along with the contacts themselves, and that combination matters, because a scorched terminal on an old harness can make a perfectly good new switch look defective within a matter of days.
Disconnect the vacuum from power before opening the housing to get at it. Note how the old harness was routed before pulling it, so the replacement can follow the same clear path away from moving parts, since a harness left rubbing against the motor housing will chafe through and reproduce the exact fault the swap was meant to fix.
Of the electrical jobs on a backpack machine, this ranks among the more approachable ones, since the switch and its wiring come out and go back in as a single connector-terminated piece rather than a set of contacts wired by hand.
- Part: C352-2800, switch and wiring harness
- Fits: Carpet Pro SCBP1, Powr-Flite PF300BP, PF600BP, PF1000BP
- Function: on/off switching bundled with its connecting harness
- Install: route clear of the motor housing to avoid chafing
- Watch for: random dropouts, a switch that needs wiggling to start
